Name: Sanitary Napkin Production Line WM-SN101 Humanized Design Gentle Embossing Technology
Brand: Quanzhou Womeng Intelligent Equipment Co., Ltd.
SKU: WM-SN101
Price: 300,000.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Womeng

Certification: CE,ISO

Model Number: WM-SN101

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $250000~$350000

Packaging Details: Seaworthy Wooden Box

Delivery Time: 90-120days

Payment Terms: L/C,T/T

Supply Ability: 40sets/year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                WM-SN101 Sanitary Napkin Production Line, Humanized Design Sanitary Napkin Production Line, Gentle Embossing Sanitary Napkin Production Line


Raw Material:	Fluff Pulp, SAP, Non-woven Fabric	Cutting System:	Servo Motor Control
Warranty:	1 Year	After-Sales Service:	Engineers Available To Service Machinery Overseas
Packaging System:	Automatic Bagging And Sealing	Control System:	PLC Control
Working Type:	Automatic	Qualified Rate:	≥98%

Raw Material:	Fluff Pulp, SAP, Non-woven Fabric
Cutting System:	Servo Motor Control
Warranty:	1 Year
After-Sales Service:	Engineers Available To Service Machinery Overseas
Packaging System:	Automatic Bagging And Sealing
Control System:	PLC Control
Working Type:	Automatic
Qualified Rate:	≥98%

Sanitary Napkin Production Line WM-SN101 Humanized Design Gentle Embossing Technology

Sanitary Napkin Production Line WM-SN101

Humanized Design with Gentle Embossing Technology

Key Attributes

Attribute	Value
Raw Material	Fluff Pulp, SAP, Non-woven Fabric
Cutting System	Servo motor control
Warranty	1 year
After-Sales Service	Engineers available to service machinery overseas
Packaging System	Automatic bagging and sealing
Control System	PLC control
Working Type	Automatic
Qualified Rate	≥98%

Product Description

This sanitary napkin production line features humanized design with attention to detail. The gentle embossing technology enhances product softness and permeability while ensuring comfortable fit.

Technical Specifications

Product size	M: 680X450 L: 800X650 XL: 950X760 (Customizable)
Product structure	Upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven, ADL non-woven, leak guard hydrophobic non-woven back sheet, waist band non-woven, color pattern sticker, elastic waist band, discarding sticker
Control system	PLC control system with HMI operating on LED touch screen, configured with HDTV monitor
Drive system	Servo Drive (Easy to change size), timing belt and flat belt are import products, all key parts use import bearings
Tension system	Top tissue paper, bottom tissue paper, hydrophobic nonwoven (leg cuff), top nonwoven, ADL, back sheet, elastic nonwoven adopt A&B shaft active unwinding by inverter motor
Safety system	Safety device on operating side with emergency stop switch. High audio fan uses sound insulation or silencer
Packaging system	Customizable with palletizer machine (double push double exit) adjustable
Materials corrective system	International brand deviation correction system
Power	380V, 50HZ three phase five wire
Machine Capacity	400KW (Excluding glue machine and air compressor)
Bleed pressure	0.6-0.8Mpa (Air compressor needs to be prepared by customers)
Machine weight	50 Tons approximately

Frequently Asked Questions

Q1. When can I get the price?

We typically provide quotes within 24 hours of receiving your inquiry. For urgent requests, please notify us by email for priority handling.

Q2. How can I get a sample to check your quality?

After price confirmation, we invite you to visit our factory to observe our production processes and product quality firsthand.

Q3. Can you do the machine's appearance design for us?

Yes, our professional team has extensive experience in machine appearance and structural design, customized to your specific production requirements.

Q4. What's your after sale service?

We provide comprehensive support including engineer visas for on-site installation. Upon machine arrival at your facility, our engineers will be dispatched immediately. Training at our factory is also available.

Q5. Could you also supply raw materials?

Yes, we maintain long-term partnerships with quality raw material suppliers who offer competitive pricing as part of our complete service package.
