Name: WM-B1119 Diaper Production Line 380V 50HZ Power 400KW Capacity
Brand: Quanzhou Womeng Intelligent Equipment Co., Ltd.
SKU: WM-B1119
Price: 475,000.00 USD
Availability: InStock

Product Details

Place of Origin: Quanzhou City,China

Brand Name: Womeng

Certification: CE,ISO

Model Number: WM-B1119

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: $400000-$550000/piece

Packaging Details: Seaworthy Wooden Box

Delivery Time: 120~150days

Payment Terms: T/T,L/C

Supply Ability: 30sets/year

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                WM-B1119 Diaper Production Line, 380V 50HZ Power Diaper Production Line, 400KW Capacity Diaper Production Line


Core Component:	PLC, Engine, Motor	Rejection Rate:	≤3%
Stable Speed:	800pcs/min	After-Sales Service:	Engineers Available To Service Machinery Overseas
Power Supply:	380V, 50Hz	Sizes:	S/M/L/XL

Core Component:	PLC, Engine, Motor
Rejection Rate:	≤3%
Stable Speed:	800pcs/min
After-Sales Service:	Engineers Available To Service Machinery Overseas
Power Supply:	380V, 50Hz
Sizes:	S/M/L/XL

WM-B1119 Diaper Production Line 380V 50HZ Power 400KW Capacity

WM-B1119 Diaper Production Line

380V 50HZ Power | 400KW Capacity | 800pcs/min Production Speed

Key Specifications

Core Component	PLC, Engine, Motor
Rejection Rate	≤3%
Stable Speed	800pcs/min
After-Sales Service	Engineers available to service machinery overseas
Power Supply	380V, 50Hz
Sizes	S/M/L/XL

Product Overview

Our intelligent baby diaper production line combines advanced technology with environmental responsibility. The system features:

IoT tracking and green warehousing for efficient raw material delivery
3D printing assistance and intelligent molding for personalized customization
Bio-based materials and degradable adhesives for reduced environmental impact
Clean water jet cutting technology
Eco-friendly paper packaging with intelligent labeling
Blockchain-managed automated control system for transparent data tracking

Technical Specifications

Product size	25m6m3m (for reference only)
Product structure	Upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven, ADL non-woven, leak guard hydrophobic non-woven back sheet, waist band non-woven, color pattern sticker, elastic waist band, discarding sticker
Control system	PLC control system, HMI operating on LED touch screen, configured with HDTV monitor
Drive system	Servo Drive (easy size change), import timing belts/flat belts, import bearings for key parts
Tension system	A&B shaft active unwinding by inverter motor for all material types
Safety system	Operating side safety devices, emergency stop switch, sound-insulated high audio fan
Packaging system	Customizable with palletizer machine (double push double exit adjustable)
Power	380V, 50HZ three phase five wire
Machine Capacity	400KW (Excluding glue machine and air compressor)
Bleed pressure	0.6-0.8Mpa (Customer provides air compressor)
Machine weight	70 Tons approximately

Frequently Asked Questions

Why choose our machine?

Professional factory with high quality and competitive pricing
24/7 online support (before and after sales)
12 months quality warranty
Overseas engineer service available

How to operate and maintain the machine?

We provide professional technicians to assist until your workers can operate the machine independently (buyer covers technician expenses).

Do you have QC or safety standards?

Yes, we maintain a strict quality control department to ensure product excellence.

How to find matching accessories?

You can purchase from us at competitive prices or source locally - most accessories use standard components.

How much does this machine cost?

Pricing depends on:

Jumbo roll (parent roll) width requirements
Inclusion of embossing/printing units
Daily production capacity needs
Optional color glue for enhanced visual appeal
