Quanzhou Womeng Intelligent Equipment Co., Ltd.
jessie@wm-machinery.com
86--18859442931
Product Details
Place of Origin: Quanzhou City,Fujian Province,China
Brand Name: WOMENG
Certification: CE,ISO9001
Model Number: WM-JSN08
Payment & Shipping Terms
Minimum Order Quantity: 1piece
Price: $350000~$500000
Packaging Details: Seaworthy Wooden Box
Delivery Time: 60-100 days
Payment Terms: L/C,T/T
Supply Ability: 12sets/year
|
Operator:
|
2-3 Persons
|
Hs Code:
|
84418090
|
After-sale Service:
|
Engineers Service Oversea/Video Technical Support
|
Warranty:
|
12months
|
Machinery Test Report:
|
Provided
|
Regional Customization:
|
Support
|
|
Operator:
|
2-3 Persons
|
|
Hs Code:
|
84418090
|
|
After-sale Service:
|
Engineers Service Oversea/Video Technical Support
|
|
Warranty:
|
12months
|
|
Machinery Test Report:
|
Provided
|
|
Regional Customization:
|
Support
|
| Production Speed | 800-1200 pieces per minute |
| Product Size | 240mm,290mm,320mm,420mm(Customized according to customer requirement) |
| Production Yield Rate | ≥98% |
| Weight | About 50 tons |
| Machine Size | 25x4x3m |
| Safety System | It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer. |
| Raw Material | Fluff pulp, SAP, non-woven fabric, PE film |
| Control System | PLC control system(Mitsubishi),HMI Operating on the LED touch |
| Drive system | Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings. |
| Power | 240V,50Hz,3 Phase Five Wire |
Technical features:
* Compact design, easy operation & maintenance
* Modular design, for future upgrading
* Low consumption, high efficiency
* Servo or frequency inverter transmission
* Touch screen for man-machine conversation
* Auto record and calculation of process data
* Main raw material auto splicing at zero speed
* Inverter or servo unwinding with tension control
* Web guiding controller
* Sensor quality control systems
* Material broken and lost inspection, auto machine stops and defective products auto rejection
* Easy size changing and manufacture
| Core Structure | Sub-Structure | Main Materials | Key Features |
| Surface Layer | Skin-Friendly Layer | Combed Cotton,Bamboo Fiber | Soft, skin-friendly, breathable |
| Breathable Layer | Microporous Non-Woven Fabric | Moisture-wicking, reduces stuffiness | |
| Distribution Layer | Rapid Penetration Layer | High-Puff Non-Woven Fabric | Fast liquid absorption, no local accumulation |
| Despersion Layer | Patterned Non-Woven Fabric | Even liquid distribution | |
| Absorbent Core | SAP Locking Layer | Super Absorbent Polymer (SAP) | High water absorption, anti-reverse osmosis |
| Support Layer | Fluff Pulp, Hollow Fiber | High water absorption, anti-reverse osmosis | |
| Leak-Proof Bottom | PE Breathable Film | Polyethylene Breathable Film | Waterproof, breathable |
| Anti-Slip Adhesive | Medical-Grade Adhesive | Secure fit, no displacement | |
| Wings | Fixing Wings | Rigid Non-Woven Fabric | Anti-side shift |
| Leak-Proof Edges | Elastic Non-Woven Fabric | Enhanced side leakage protection |
Quanzhou Womeng Intelligent Equipment Co., Ltd. is a trusted diaper production machine line manufacturer, established in 2016 in Quanzhou—East Asia’s cultural hub and the origin of the Maritime Silk Road. We focus on the development, production, and sales of high-efficiency diaper machines and related equipment.
Our main products include nappy making machine, adult diaper machine, menstrual pad machine, and diaper packaging machine, along with sanitary napkin, pant diaper, mattress, and pad production lines.
With a skilled team and modern facilities, Womeng customizes each diaper making machine to meet specific market needs, ensuring stable performance and quality output. We’re committed to providing both excellent equipment and professional technical support to clients worldwide.
